企业微信号：vibloc@hotmail.comC-KQ2T10-01S,外螺Y型接头,快换接头 - C-KQ系列（普通型）
产品简介:
|
ΦP |
型 号 |
S |
T |
ΦD |
B |
L1 |
L2 |
A |
M |
|
Φ4 |
C-KQ2T 04-01S |
14 |
R1/8 |
10.5 |
4.6 |
18.1 |
22.1 |
36.1 |
16.1 |
|
C-KQ2T 04-02S |
R1/4 |
26.1 |
38.1 | ||||||
|
Φ6 |
C-KQ2T 06-01S |
R1/8 |
12.9 |
5.4 |
20.1 |
23.1 |
39.1 |
17.1 | |
|
C-KQ2T 06-02S |
R1/4 |
27.1 |
41.1 | ||||||
|
C-KQ2T 06-03S |
R3/8 |
29.1 |
42.6 | ||||||
|
C-KQ2T 06-04S |
22 |
R1/2 |
33.7 |
43.6 | |||||
|
Φ8 |
C-KQ2T 08-01S |
17 |
R1/8 |
15.3 |
6.1 |
23.1 |
24.6 |
43.6 |
18.6 |
|
C-KQ2T 08-02S |
R1/4 |
28.6 |
45.6 | ||||||
|
C-KQ2T 08-03S |
R3/8 |
30.6 |
47.2 | ||||||
|
C-KQ2T 08-04S |
22 |
R1/2 |
34.6 |
49.7 | |||||
|
Φ10 |
C-KQ2T 10-01S |
19 |
R1/8 |
18.6 |
6.9 |
26.6 |
27.1 |
49.7 |
21.1 |
|
C-KQ2T 10-02S |
R1/4 |
30.1 |
50.7 | ||||||
|
C-KQ2T 10-03S |
R3/8 |
32.1 |
52.1 | ||||||
|
C-KQ2T 10-04S |
22 |
R1/2 |
36.1 |
54.6 | |||||
|
Φ12 |
C-KQ2T 12-01S |
R1/8 |
21 |
7.6 |
28.6 |
28.1 |
53.6 |
22.1 | |
|
C-KQ2T 12-02S |
R1/4 |
31.1 |
53.6 | ||||||
|
C-KQ2T 12-03S |
R3/8 |
33.1 |
55.2 | ||||||
|
C-KQ2T 12-04S |
R1/2 |
37.1 |
57.6 |
定购说明：
特点：快速方便可节约使用空间；接头螺纹涂有密封胶，可省去胶带的缠绕。
基本材料：铜；不锈钢；工程塑料；耐老化橡胶。
最高使用压力：1.0MPa(10.2kgf/cm2)用于真空系统时真空压力应限定在 10Torr以下。
使用软管材料：尼龙或PU。
适用流体：水或空气
